SpaceVibe
Space Structures GmbH
Vibration test data processing and visualization tool for faster, safer spacecraft vibration testing.
Technical specifications
- Supported file formats
- Nastran punch (PCH), universal 58 (UNV), CSV
- Standards
- ECSS-E-HB-32-26, NASA-HDBK-7004
- Comparison levels
- QSL, sine, PSD, RRS
- Performance
- Parses hundreds of channels in seconds
About
SpaceVibe is a tool to assess sine and random vibration analysis predictions against test data live during testing. It allows visualization, interpolation, scaling and notching of sine and random vibration responses (transfer functions, harmonics, random vibration), compares vibration responses against allowable levels such as QSL, sine, PSD and RRS, provides overlay plots comparing test versus prediction and pre/post-resonance search, and supports quick notch definition for sine and random vibration. It supports Nastran punch (PCH), universal 58 (UNV), and CSV file formats, was built specifically for the space sector following ECSS-E-HB-32-26 and NASA-HDBK-7004 but is applicable to any industry, and parses hundreds of channels in seconds.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
