0.9 Meter Satcom On-The-Move Antenna (V900)
ALL-SEEING TECHNOLOGY CO., LTD
Flat-array roof-mounted Ku-band SOTM antenna system providing continuous satcom connectivity to moving vehicles.
Technical specifications
- Diameter
- 0.9 m
- Operating Frequency (Receive)
- 10.95-12.75 GHz (Ku Band)
- Operating Frequency (Transmit)
- 13.75-14.5 GHz (Ku Band)
- Antenna type
- Prime focus antenna
- Sidelobe Pattern
- First side lobe level <= -14 dB
- Gain (Receive)
- 38.5 + 20lg(f/12.5GHz) dBi
- Gain (Transmit)
- 39.5 + 20lg(f/14.25GHz) dBi
- Polarization
- Linear
- Antenna G/T
- 16.3 dB/K
- Cross polarization
- >= 35 dB
- Uplink EIRP
- 55.5 dB (with ext. 40W BUC)
- Electrical Interfaces
- N (Rx) / WR75 (Tx)
- Power supply
- DC 48V, AC 110-220V 50/60Hz (Optional)
- Continuous power consumption
- 650 W (antenna) + 10 W (IDU)
- Azimuth Travel Range
- 360 deg continuous, automatically adjusted
- Elevation Travel Range
- 15-90 deg, automatically adjusted
- Polarization Travel Range
- +/-180 deg, automatically adjusted
- Initial satellite acquisition
- <60 sec, tuned on satellite beacon
- Satellite re-acquisition
- <10 sec (when loss/blockage is <20 min)
- Azimuth tracking accuracy
- 0.2 deg @ 60 deg/s, 200 deg/s^2
- Elevation tracking accuracy
- 0.9 deg @ 45 deg/s, 200 deg/s^2
- Outdoor unit size
- Diameter 135 x 75H cm
- Outdoor unit weight
- 98 kg (antenna only, excluding BUC)
About
The V Series is a waveguide-array-type satcom-on-the-move antenna system built as an integrated unit for mobile satellite communication. It combines fiber-optic gyro inertial navigation with beacon tracking to maintain lock during sharp turns and on bumpy roads, working with all Ku-band communication satellites so the equipped vehicle can continuously and accurately track a satellite during movement, enabling uninterrupted multimedia communication with a central station. The whole system integrates on the antenna turntable for a high-precision, low-profile, rugged, easy-to-install roof-mounted design. After the system starts, acquisition and tracking complete automatically without manual operation, whether the vehicle is moving or stationary; if signal is lost, re-acquisition takes only about 3 seconds, with a maximum transmission data rate of 4 Mbps. The outdoor antenna/turntable mounts on the vehicle roof while the antenna control unit (ACU) is a 1U 19-inch rack-mount unit installed in the vehicle cabin. Configuration includes the antenna/feed system, waveguide/connection cable/slip rings, azimuth-elevation turntable and servo drive, antenna control system, fiber-optic gyro inertial navigation system, and tracking receiver. Available in 0.6m, 0.8m and 0.9m sizes.
