VRW-A-1 Reaction Wheel
VECTRONIC Aerospace GmbH
A-series reaction wheel with 6 Nms angular momentum in a compact housing.
Technical specifications
- Dimensions
- 115 mm x 115 mm x 80 mm
- Mass
- 1.9 kg
- Moment of Inertia (rotor)
- 2.0×10⁻³ kgm²
- Mounting Pattern
- 4x M5, 96 mm x 96 mm
- Power Consumption (steady state, no speed)
- <1.4 W
- Power Consumption (steady state, max speed)
- <15 W
- Power Consumption (max torque, max speed)
- <110 W
- Input Voltage Range
- 10 VDC to 47 VDC
- Signal Interface
- RS422 / RS485 / CAN
- Connector Type
- MDM-25
- Operating Temperature Range
- -20°C to +70°C
- Storage Temperature Range
- -40°C to +80°C
- Vibration
- 26 g rms random 3 axis
- Radiation Tolerance
- >20 krad
- Max. Speed
- ± 6000 rpm
- Max. Angular Momentum
- 6 Nms
- Max. Torque
- ± 90 mNm
- Speed Control Loop Accuracy (2σ)
- 0.1 rpm
- Unbalance Static/Dynamic
- < 3 gmm / 100 gmm²
About
The VRW-A-1 is an A-series reaction wheel from VECTRONIC Aerospace offering 6 Nms of angular momentum in a more compact envelope than the equivalent D-series wheel. It shares the VRW family’s brushless DC motor, 32-bit microprocessor PI-loop speed controller and four-quadrant PWM drive electronics, with torque or speed control over RS422/RS485/CAN, radiation tolerance above 20 krad and in-orbit lifetime exceeding 45,000 hours.
