LEOS-100HP Satellite Platform
Berlin Space Technologies
Microsat platform with 2 kW payload power capacity, 150 kg system mass, electric propulsion, and X-Band 320 Mbit/s downlink for demanding LEO missions.
Technical specifications
- System Mass
- 150 kg (with electric propulsion)
- Payload Mass
- 50–75 kg
- Payload Volume
- 600 × 600 × 600 mm
- Payload Peak Power
- 2000 W
- Payload Average Power
- 300 W
- TT&C
- S-Band
- Data Downlink
- 320 Mbit/s X-Band
- Propulsion
- Electric, ≥100 m/s ΔV
- Payload Data Storage
- 1 TB per DPU
- ADCS
- 3-axis stabilized
- Design Life
- 5 years LEO
About
The LEOS-100HP is a high-power variant of the LEOS-100 microsat platform built on proven LEOS-50 avionics. Designed for missions requiring up to 2 kW payload power with 50–75 kg payload capacity. Features 3-axis stabilized ADCS, S-Band TT&C, X-Band 320 Mbit/s downlink, and electric propulsion providing ≥100 m/s ΔV. 1 TB payload data storage per DPU. Design life 5 years LEO.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
