TA1007
Triad RF Systems
500-2800 MHz, 5 W GaAs power amplifier module supporting simple CW/FM through highly modulated 64/256QAM signals.
Technical specifications
- Frequency Low (MHz)
- 500
- Frequency High (MHz)
- 2800
- P1dB dBm (Typ)
- 36
- Tx Gain (dB)
- 39
- Supply Voltage (Vdc)
- 11-13
- Size (in)
- 5 x 2.5 x 0.553
About
The TA1007 PA module has been engineered to support any signal type, from simple CW/FM signals to complex, highly modulated carriers such as 64 and 256QAM. This module uses the latest GaAs transistor technology to achieve highly linear power with low distortion, or peak power at high efficiencies to meet any radio system’s requirements. Triad employs the latest RF simulation and design methods to offer products with the lowest size, weight, and DC power consumption in the industry. Features: Over / Under / Reverse Voltage Protection, High Speed On/Off Control, Optional Heatsink. Applications: Simple CW to Highly Modulated Signals, Commercial / Military Radio Systems, Software Defined Radios, General Purpose RF Amplification.
