THPR1060
Triad RF Systems
Range Enhanced Silvus StreamCaster S-Band radio system, 4-channel MIMO with 120 W total amplified Tx power.
Technical specifications
- Radio Core
- Silvus
- Band
- S
- MIMO Streams
- 4
- Frequency Low (MHz)
- 2200
- Frequency Hi (MHz)
- 2500
- Total THPR Power (W)
- 120
- Size (in)
- 9.21 x 5.77 x 5.35
About
The THPR1060 Triad High Power Radio (THPR) contains a Silvus StreamCaster SC4410-235-O radio at its core and combines with Triad’s high-power RF subsystems in a low SWaP package. This 4 channel, S-Band amplified radio integrates the necessary Silvus radio, RF amplification, control circuitry, and interfaces to achieve higher RF output power, greater throughput, and longer link distances than the stand-alone radio. Offering +22 to +32 VDC input voltage, this THPR contains BDAs, RF filtering, and innovative SoC-based monitoring and controls, with real-time power measurement and link diagnostics. Features: 2200-2500 MHz S-Band coverage, 120W (30W per channel) amplified Tx power, integrated Silvus SC4410-235-O MIMO radio, compatible with other Silvus radios and networks, optional cooling fans. Applications: Long distance high data rate ISR links, UAS/UGV/USV video and data links, military MANET, maritime high-throughput LOS/NLOS systems, point-to-point and mesh networking.
