AHP5354A Active Multiband L1/L5 GNSS High Precision Patch Antenna
Taoglas
Multi-band active GNSS patch antenna delivering high-precision positioning for GPS/BeiDou/GLONASS/Galileo.
Technical specifications
- GNSS type
- Active
- GNSS bands
- L1/L5
- Frequency range
- 1176-1610 MHz
- Gain max
- 29.2 dBi
- Connector
- I-PEX MHF I (Right Angle)
- Dimensions
- 35 x 35 x 10 mm
- Cable
- 100 mm, 1.37 mm micro coax
- Impedance
- 50 Ohm
- VSWR
- 2:1
- Mounting
- Adhesive, Screw
- Polarity
- RHCP
- Operating temperature
- -40C to +85C
- Weight
- 34.5 g
About
The AHP5354A is the active variant of Taoglas’s HP5354 Inception design, a compact 35 x 35 x 10 mm ceramic patch antenna optimized for high-precision GNSS positioning. It covers BeiDou (B1/B2a), GPS/QZSS (L1/L5), GLONASS (G1), and Galileo (E1/E5a) bands, tuned on a 70 x 70 mm ground plane. Designed for navigation, robotics, precision agriculture, and autonomous vehicles; ships with 100 mm of 1.37 mm micro coax cable and an I-PEX MHF I right-angle connector.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
