Eddie
Spacemanic s.r.o.
Flight-proven on-board computer for command and data handling and payload processing in small satellite missions.
Technical specifications
- Operating temperature
- -40 C to +85 C
- Dimensions
- 67 x 42 x 7.5 mm
- Mass
- 25 g
- Power supply
- 3.3 V / 5 V (for CAN)
- Power consumption
- 60 mW average, 100 mW peak
- Operating system
- FreeRTOS-based
- On-board sensors
- Gyroscope, accelerometer, magnetometer, temperature
- Microcontroller
- MSP430
- Clock speeds
- 32.768 kHz (low-power) / 16 MHz (standard)
- Memory
- 6 x 1 MiB external FRAM
- Interfaces
- 1x I2C + 1x isolated I2C, 1x RS485, 1x UART, 1x CAN, 1x SPI, 3x PWM, 8x GPIO (4x ADC 12-bit, 3.3V)
- Flight heritage
- 8+ CubeSat missions (LASARSat, GRBBeta, Veronika, and more)
About
Eddie is a flight-proven, reliable on-board computer designed for satellite command and data handling and payload processing in small satellite missions. It is compact, robust, and ready to fly, running a FreeRTOS-based operating system with an MSP430 microcontroller, and has flown on 8 or more CubeSat missions.
