Amun
Spacemanic s.r.o.
PC/104 form-factor power management unit for 0.5U-2U CubeSats.
Technical specifications
- Operating temperature
- -40 C to +85 C
- Dimensions
- 95.9 x 90.2 x 19.7 mm (0.2U)
- Mass
- 185 g
- Power outputs
- 1x fixed 3.3 V, 1x fixed 5 V, 4x configurable 3.3V/5V, 1x VBAT
- Battery configuration
- 2S1P
- Battery capacity
- 24 Wh
- Battery voltage
- Typical 7.2 V, max 8.2 V
- Thermal control
- Manual or automatic
- Interfaces
- 1x I2C, 1x RS485, 2x UART, 1x CAN
- Flight heritage
- 7 CubeSat missions (LASARSat, GRBBeta, Veronika, and more)
About
Amun delivers reliable power management for small satellites, ensuring stable operation across mission-critical systems. Designed in the PC/104 form factor, it is intended for 0.5U-2U CubeSats and integrates easily into modular satellite platforms, and has flown on 7 CubeSat missions.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
