AirSAR-Alpha-X
Sisir Radar
Multi-channel X-band SAR payload for airborne platforms, delivering ultra high-resolution imagery at 0.3-0.5 m resolution.
Technical specifications
- Frequency of Operation
- 9-10 GHz (X Band)
- Altitude
- Up to 1 km AGL
- Imaging Range
- 5 km from nadir
- Range Resolution
- 0.3-0.5 m
- Azimuth Resolution
- 0.3-0.5 m
- Optional Add-on Features
- Hybrid/Full Polarimetry; Repeat Pass Interferometry
- IMU/GNSS
- Embedded high-performance IMU/GNSS unit
- Payload Weight
- 15 kg (including antenna)
- Power Consumption
- Internal 60,000 mAh, 150 W rechargeable power source
- Payload Dimension
- 400 x 400 x 200 mm
About
AirSAR-Alpha-X (Model No: SRPL AIRSAR-ALPHA-X1) is a multi-channel X-band Synthetic Aperture Radar payload engineered for uncompromising, ultra high-resolution imagery. Optimised for size, weight and power (SWaP), it integrates with tactical UAVs, VTOL platforms, fixed-wing UAVs and manned aircraft. Its proprietary airborne SAR processor uses a precision motion-compensation algorithm to guarantee image fidelity across all airborne platforms, including low-altitude, low-velocity drones. The payload and processor software natively support hybrid and full polarimetric modes as well as advanced interferometric processing, making it suited to demanding operational and research applications. It shares its airframe integration approach with Sisir Radar’s L-band AirSAR-Alpha family.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
