Q40 MicroPNT GNSS Receiver
QinetiQ Space
Multi-constellation military GNSS receiver with <5 ns timing accuracy, anti-jamming/anti-spoofing, and RAIM for C5ISR and land/air platforms.
Technical specifications
- Dynamics
- <600 m/s
- Timing Accuracy
- <5 nanoseconds
- Constellations
- Multi-constellation (GPS, Galileo)
- Anti-Jamming/Spoofing
- Advanced digital signal processing
- Integrity
- RAIM
- ITAR Status
- Non-ITAR, UK-sovereign supply chain
- Applications
- C5ISR, land vehicles, dismounted soldiers, UAVs
- UK MOD Contract
- £67M Robust Global Navigation System (R-GNS)
About
The QinetiQ Q40 MicroPNT is a compact multi-constellation, multi-frequency GNSS receiver designed for military and defence applications demanding resilient Position, Navigation, and Timing (PNT) in contested and GNSS-degraded environments. It handles dynamics up to 600 m/s, delivering timing accuracy of under 5 nanoseconds with advanced digital signal processing for anti-jamming and anti-spoofing protection, and Receiver Autonomous Integrity Monitoring (RAIM).
The Q40 MicroPNT is Non-ITAR and built from a UK-sovereign supply chain. It has been selected for the UK MOD’s £67 million Robust Global Navigation System (R-GNS) programme. Applications span C5ISR, dismounted soldier systems, land vehicles, and UAVs, and it is qualified to military temperature, shock, vibration, and EMC standards.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
