General Hyperspectral Series Satellites
Zhongke Xingchen
Hyperspectral satellite for water resource management, land monitoring and urban expansion analysis, with 40 m hyperspectral and 10 m panchromatic cameras.
Technical specifications
- Representative satellite
- Xiguang-1 03 (Xiamen Science and Technology No.1)
- Imaging mode
- Pushbroom imaging
- Load index
- Hyperspectral camera
- Spatial resolution
- 40m/10m
- Width
- 80km@500km
- Spectral range
- 450nm~900nm
- Number of spectral segments
- 150/300
- Spectral resolution
- 2.8nm/1.4nm
- Load index 2
- Panchromatic camera
- Spatial resolution (panchromatic)
- 10m
- Width (panchromatic)
- 80km@500km
- Total star weight
- 55kg
About
The general-purpose hyperspectral satellite is suitable for tasks such as water resource management, land monitoring, and urban expansion analysis. Equipped with a 40-meter hyperspectral camera and a 10-meter panchromatic camera, it has an 80 km swath width and can accurately identify land cover, vegetation conditions, and water quality. Representative satellite: Xiguang-1 03 (Xiamen Science and Technology No.1).
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
