Test Space – Thermal Vacuum & Vibration Testing
TRL Space
Combined thermal-vacuum and vibration test facility in Brno for space, defence, automotive and electronics hardware qualification.
Technical specifications
- TVAC - Internal volume
- 900 x 600 x 600 mm
- TVAC - Temperature range
- -70 C to +200 C
- TVAC - Temperature stability
- +/-0.01 C to +/-0.05 C
- TVAC - Max cooling rate
- ~1.8 C/min
- TVAC - Time to 1e-5 mbar
- < 30 minutes
- TVAC - Ultimate vacuum
- < 1e-6 mbar
- TVAC - Live feedthrough channels
- 100 (2x Sub-D 50-way, 500 V DC, 5 A/pin)
- TVAC - Viewport
- DN160, illuminated
- TVAC - Frame/walls
- Stainless steel 1.4301, aluminium removable walls
- TVAC - Compliance
- ECSS-E-ST-10-03C (Rev.1, 2022)
- Vibration - Shaker type
- Electrodynamic, max frequency 2600 Hz
- Vibration - Force (sine)
- 45 kN
- Vibration - Force (random)
- 45 kN rms
- Vibration - Force (shock)
- 90 kN (80 kN in HVS mode)
- Vibration - Max acceleration
- 900 m/s2 (sine) / 630 m/s2 rms (random) / 1800 m/s2 peak (shock)
- Vibration - Max velocity
- 2 m/s continuous, up to 3.5 m/s peak
- Vibration - Max displacement
- 76.2 mm pk-pk
- Vibration - HVS shock mode
- Pulse velocity up to 4.6 m/s
- Vibration - Sliding table
- 1050 x 1050 mm magnesium, up to 1,654 kg, 2000 Hz max
- Vibration - Head expander (optional)
- 1000 x 1000 mm, up to 1,000 Hz
- Vibration - Power draw
- 57 kVA (ECO-mode reduces up to 80%)
- Vibration - Control system
- IMV K2+ with standards-based test generation, remote monitoring
About
Test Space is an environmental testing facility that integrates thermal vacuum, vibration, and cleanroom testing capabilities under one roof, operated by satellite engineers and serving space, defence, automotive, and electronics customers. It eliminates inter-site logistics risk and offers end-to-end testing expertise and custom support throughout qualification campaigns.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
