Teledyne e2v CCD290-99 Large-Area Back-Illuminated Scientific CCD
Teledyne e2v
Large-area, back-illuminated scientific CCD image sensor for demanding astronomical and scientific imaging applications, with very low read-out noise for exceptional sensitivity.
Technical specifications
- Number of pixels
- 9216 (H) x 9232 (V)
- Pixel size
- 10 µm square
- Image area
- 92.2 mm x 92.4 mm
- Outputs
- 16
- Package size
- 98.5 x 93.7 mm
- Package format
- Silicon carbide with two flexi connectors
- Focal plane height, above base
- 20.0 mm
- Connectors
- Two 51-way micro-D
- Flatness
- 20 µm (peak to valley)
About
The CCD290 extends e2v’s family of scientific CCD sensors and has been designed to provide a large image area for demanding astronomical and scientific imaging applications. Back-illuminated spectral response combined with very low read-out noise give exceptional sensitivity.
The sensor has an image area having 9216 x 9232 pixels with registers at both top and bottom each with eight outputs for short read-out times. The pixel size is 10 um square. The image area has two separately connected sections to allow full-frame or split full-frame read-out modes. Depending on the mode, the read-out can be through 8 or 16 of the output circuits. A fixed-barrier dump drain is also provided to allow fast dumping of unwanted data.
The output amplifier is designed to give very low noise at read-out rates of up to 3 MHz. The low output impedance simplifies the interface with external electronics and the optional dummy outputs are provided to facilitate common mode rejection.
Typical applications: astronomy, scientific imaging.
