410-DHR Reflectometer
Surface Optics Corporation
Portable handheld directional-hemispherical infrared reflectometer, developed with NAVAIR/NRL/NIST, 0.9-12 micron, two incidence angles.
Technical specifications
- Measured quantity
- Directional-hemispherical reflectance (DHR)
- Output
- Absolute reflectance (0-1) plus calculated in-band emissivity
- Spectral bands
- 0.9-1.1, 1.9-2.6, 3.0-4.0, 3.0-5.0, 4.0-5.0, 8.0-12.0 micron
- Incidence angles
- 20 degrees and 60 degrees
- Calibration coupon
- Specular gold
- Accuracy
- +/- 0.03
- Repeatability
- +/- 0.005
- Beam spot size
- 0.50 inch
- Measurement time
- 10 sec
- Sample size (flat)
- >= 0.5-inch dia
- Sample size (curved)
- 6-inch convex / 12-inch concave
- Battery run time
- 2 hr
- Weight
- 4.7 lb
- Dimensions
- 11.54 in H x 9.04 in L x 3.27 in W
- Interface
- LCD touchscreen 1/4 VGA + trigger
About
The 410-DHR measures integrated surface reflectance at two angles of incidence (20 and 60 degrees) across six wavelength bands spanning 0.9-12 micron. It is portable, performs measurements in 10 seconds with touchscreen-guided calibration, and can be used on curved or large targets without special fixtures. Applications include infrared signature management, thermal-camera calibration, low-observable coatings characterization, emissivity measurement, and radiative heat transfer analysis.
