SCPC Wideband SDR Modem
SatixFy
Single-Channel-Per-Carrier wideband satellite modem for telco backhaul, military, and maritime applications.
Technical specifications
- Carrier bandwidth
- up to 125 MHz single carrier
- SNR dynamic range
- VLSNR -10dB to 256APSK +20dB (30dB range)
- Security
- AES-256 TRANSEC
- Redundancy
- 2-in-a-box
- ASIC
- Sx3000
- Applications
- IP trunking, telco backhaul, military, maritime, aviation
About
The SCPC (Single Channel Per Carrier) modem is a wideband software-defined-radio modem built on SatixFy’s Sx3000 ASIC, supporting single-carrier bandwidths up to 125MHz with a wide 30dB signal-to-noise-ratio dynamic range (from VLSNR -10dB up to 256APSK +20dB) and AES-256 TRANSEC encryption. It is deployed in 2-in-a-box redundant configurations for high-availability links and targets IP trunking, telecom backhaul, military, maritime, and aviation satellite communication applications.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
