SAS-2 Dual S-band Patch Antenna
Satlab A/S
Dual RHCP S-band patch antenna in a 1U footprint.
Technical specifications
- RX frequency
- 2025-2110 MHz
- RX gain
- 5.5 +/- 0.3 dBi
- RX HPBW
- 87 +/- 4 degrees
- TX frequency
- 2200-2290 MHz
- TX gain
- 6.1 +/- 0.2 dBi
- TX HPBW
- 85 +/- 4 degrees
- VSWR
- < 1.5:1
- Dimensions
- 100.0 x 80.0 x 6.8 mm
- Mass
- 107 g
About
The SAS-2 is a dual right-hand circularly polarized S-band patch antenna in a 1U footprint, supporting both receive and transmit S-band frequencies for CubeSat telemetry and command applications.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
