Satcube Secure
Satcube AB
Hardened, FIPS 140-2 Level 3 certified portable satellite terminal for TRANSEC government and defence networks.
Technical specifications
- Dimensions
- 470 x 320 x 75 mm
- Weight
- 9.5 kg
- Environmental rating
- IP65/IP67 water and dust proof
- Power
- 24 VDC, 130 W; AC/DC 100-240 VAC, 47-63 Hz
- Antenna TX
- 13.75-14.50 GHz (Ku band)
- Antenna RX
- 10.95-12.75 GHz (Ku band)
- EIRP
- 46 dBW
- G/T
- 9 dB/K
- Internal modem
- iDirect 950mp
- Approvals
- CE (RED directive 2014/53/UE, EN 301 428), FCC
- Operating temperature
- -35 C to 60 C
- Data rate
- Up to 85/20 Mbps via HTS
- Security
- FIPS 140-2 Level 3 certified TRANSEC module, AES-256 link encryption, X.509 digital certificates, automatic key management
About
Satcube Secure enables users to create an efficient and secure broadband connection in a minute anywhere in the world. It is FIPS 140-2 Level 3 certified and supports both one-way and two-way TRANSEC for mission-critical communications, suitable for governments, emergency responders, law enforcement, and public safety organizations. With the Intelsat FlexMove data plan it reaches near-global coverage, and has been cited by USSOCOM and the US Department of Defense as a force multiplier for global deployment.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
