CubeSat Platforms
ISISPACE Group
Flight-proven CubeSat platforms in 3U–16U form factors for Earth Observation, IoT, In-Orbit Demonstration, and more. 73+ satellites launched.
Technical specifications
- Available Form Factors
- 3U, 3UXL, 6U, 6UXL, 8U, 12U, 12UXL, 16U
- Payload Volume — 3U(XL)
- 1.5 – 2U
- Payload Volume — 6U(XL)
- 2.5 – 3U
- Payload Volume — 8U
- 4U
- Payload Volume — 12U(XL)–16U
- 8 – 12U
- TT&C — VHF/UHF (3U/XL)
- 9.6 kbps uplink & downlink
- TT&C — VHF/UHF (6U/XL)
- 9.6 kbps uplink / up to 0.5 Mbps downlink
- TT&C — S-Band (8U)
- 76.8 kbps uplink / up to 4.3 Mbps downlink
- TT&C — S-Band (12U/XL–16U)
- 9.6 kbps uplink / up to 0.5 Mbps downlink
- Data Bus — 3U(XL)
- I2C / SPI / UART
- Data Bus — 6U(XL)–16U
- I2C / CAN / SPI / USART / UART
- Storage
- Up to 64 GB
- Propulsion (optional, 6U–16U)
- Up to 2000 Ns total impulse
- Flight Heritage
- 73+ ISISPACE satellites launched
About
ISISPACE small satellite platforms are all based on flight-proven systems configured to optimise payload space and performance. Building on the heritage of configurations designed and launched for existing missions, ISISPACE provides a large range of platform configurations that meet the performance requirements of diverse applications including Earth Observation, In-Orbit Demonstration and Verification, Air Quality Monitoring, Ship Tracking, Signal Intelligence, Climate Action, Education, and Internet of Things (IoT).
As every mission comes with different requirements, ISISPACE has focused on a design philosophy that enables the right balance between flexibility, compatibility, and reliability — allowing customer teams to focus on the mission and payload while reducing time-to-orbit. All subsystem electrical, mechanical, and software interfaces are verified during the platform Assembly, Integration, and Verification (AIV) phases by ISISPACE experts and dedicated quality engineers.
Platforms are available in 3U, 3UXL, 6U, 6UXL, 8U, 12U, 12UXL, and 16U form factors. Engineering model platforms containing the core avionics systems are also offered, ideal for payload interface development and flight software validation. Optional propulsion integration is available for 6U and larger platforms (up to 2000 Ns total impulse). 73+ ISISPACE satellites have been successfully launched to date.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
