ANT-100
AAC Clyde Space
Deployable UHF/VHF antenna system for CubeSats enabling ground station communication in amateur frequency bands.
Technical specifications
- Frequency Bands
- UHF (400-450 MHz), VHF (130-175 MHz)
- Deployment Mechanism
- Burn-wire / shape-memory alloy
- Interface
- I2C
- Power (deployment)
- ~1.5 W
- Mass
- ~35 g
- Stowed Dimensions
- ~90 x 90 x 6 mm
- TRL Level
- 9
About
The ANT-100 is a deployable antenna system for CubeSats operating in UHF and VHF frequency bands. It supports amateur radio and standard ground-station communication links for telemetry and command. The system uses shape-memory alloy or burn-wire deployment mechanisms and is compatible with standard CubeSat EPS systems.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
