T-Minus CanSat Launcher
Reusable, parachute-recovered rocket launcher deploying up to 6 CanSats above 1km altitude.
Description
The T-Minus CanSat Launcher is a solid-propellant rocket vehicle designed to launch and deploy up to six CanSat-format educational or technology-demonstration payloads to altitudes above 1km. The vehicle is parachute-recovered and reusable across multiple flights, making it well suited for university and STEM CanSat competition programs as well as low-cost payload testing campaigns. It is built by T-Minus Engineering using the same in-house solid propellant manufacturing and mechanical/electrical integration capability used for the company's DART sounding rocket program.
Specifications
| Height | 3.17 m |
|---|---|
| Diameter | 0.2 m |
| Total mass | ~23 kg |
| Motor total impulse | 4300 Ns |
| Burn time | 4.2 s |
| Payload capacity | up to 6 CanSats |
| Recovery | parachute, reusable |
