RIXSCam Mini
XCAM
Single-detector photon counting camera with micron-level spatial resolution for RIXS research.
Technical specifications
- Total Active Area
- 26.11 x 25.73 mm
- Active Pixels (H x V)
- 1632 x 1608
- Pixel Size
- 16 x 16 µm
- Readout Rate
- 3 MHz
- System Noise (HR Output)
- ≤15 e⁻
- System Noise (LS gain of 150)
- ≤1 e⁻
- System Noise (no LS gain)
- ≤100 e⁻
- Vacuum Compatibility
- 1E-9 mbar
- Temperature Control
- -70°C to -40°C
- Spatial Resolution
- <5 µm
About
RIXSCam Mini is a high-precision X-ray detector engineered for Resonant Inelastic X-ray Scattering (RIXS) research, delivering single-photon detection with micron-level spatial resolution. It combines ultra-low read noise with advanced centroiding algorithms and uses Peltier cooling as a cost-effective alternative to cryogenic cooling, with a replaceable back-illuminated EMCCD detector for extended system lifetime.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
