MEGA Multi-Beam Electronic Antenna (MEOLUT Phased Array)
TTI Norte
Electronically-steered, no-moving-parts L-band phased array antenna for simultaneous multi-satellite Galileo/GLONASS/GPS Search & Rescue (MEOLUT) tracking.
Technical specifications
- Frequency band
- L-band
- Antenna type
- Planar phased array, no moving parts
- Simultaneous signals
- Up to 6
- Compatible constellations
- Galileo, GLONASS, GPS
- Beam steering
- Electronic, instantaneous
- Maintenance
- Self-calibrating, graceful degradation on element failure
- Dish replacement ratio
- Replaces up to 4 traditional MEOLUT dishes
About
The MEGA (Meolut Multi-beam Electronic Antenna) phased array antenna predicts the presence and pointing direction of beams from the array’s feeding complex vector, enabling simultaneous multi-satellite tracking without mechanical re-positioning. It is compatible with Search & Rescue (SAR) systems operating over GNSS constellations including Galileo, GLONASS and GPS, and can receive and process up to 6 signals simultaneously, improving throughput and localization accuracy while providing built-in redundancy. MEGA replaces up to 4 traditional MEOLUT dishes with a single electronically-steered planar array, offering instantaneous beam steering, self-calibration (no re-calibration needed), graceful degradation if individual elements fail, and a reduced operational footprint and maintenance downtime.
Documentation
Need the full ICD, test reports or a specific revision? Ask the supplier directly.
