Space-Grade Blower (ECLSS)
ASPINA
ASPINA’s space-grade blower was developed for JAXA’s CO2 Removal System demonstration and launched to the International Space Station in October 2025 aboard H3 Rocket No. 7. Rated at 60,000 rpm with 71,000 rpm maximum, the blower delivers 200 L/min airflow at 10 kPa pressure. Applications include space station ventilation, CO2 scrubbing, harmful substance removal, and […]
Technical specifications
- Rated Speed
- 60,000 rpm
- Max Speed
- 71,000 rpm
- Flow Rate
- 200 L/min
- Pressure
- 10 kPa
- Power
- 24V, 100W max
- Mass
- 300 g
- TRL
- 9
- Heritage
- ISS JAXA CO2 removal system (Oct 2025)
About
ASPINA’s space-grade blower was developed for JAXA’s CO2 Removal System demonstration and launched to the International Space Station in October 2025 aboard H3 Rocket No. 7. Rated at 60,000 rpm with 71,000 rpm maximum, the blower delivers 200 L/min airflow at 10 kPa pressure. Applications include space station ventilation, CO2 scrubbing, harmful substance removal, and exploration rover environmental control.
Documentation
No public datasheet yet — request the datasheet / ICD from the supplier.
