A rugged, handheld real-time spectrum analyzer in a tablet form factor, offered in configurations up to 18 GHz for detecting and geolocating RF interference during live satellite ground station operation.
SPECTRAN V6 TABLET
A rugged, handheld real-time spectrum analyzer in a tablet form factor, offered in configurations up to 18 GHz for detecting and geolocating RF interference during live satellite ground station operation.
Description
The Aaronia SPECTRAN V6 TABLET is a mobile, handheld real-time RF spectrum analyzer built into a compact, portable tablet form factor. It combines an AMD Ryzen 7 processor, 64 GB RAM, and ultra-fast PCIe 4.0 storage with a dedicated RF front end, giving field engineers desktop-class real-time spectrum analysis performance in a device that can be carried to an antenna site or ground station. Depending on configuration, the tablet family spans 9 kHz up to 140 GHz, with sweep speeds up to 3 THz/s and real-time bandwidths up to 490 MHz. The 18 GHz variant was introduced as the world's first portable real-time spectrum analyzer capable of well over 1.5 THz/s sweep speed at an 18 GHz span, purpose-built to detect and locate RF interference during live operation of satellite ground stations. The device runs Aaronia's RTSA-Suite PRO software on Windows 11 Pro or Linux, offers up to 16 TB of internal storage for continuous signal recording, and features a sunlight-readable, outdoor-rated touchscreen. Target users include satellite ground segment operators, SatCom interference hunters, spectrum regulators, and military/aerospace RF engineers.
Specifications
| Frequency range (family) | 9 kHz up to 18 GHz (model-dependent, up to 140 GHz across full V6 line) |
|---|---|
| Real-Time Bandwidth | 44 MHz (up to 490 MHz on other V6 tablet variants) |
| Sweep speed | max. 3 THz/s; well over 1.5 THz/s at 18 GHz span |
| Sensitivity (DANL) | -170 dBm/Hz |
| Internal storage | max. 16 TB |
| Operating system | Windows 11 Pro / Linux |
| Processor | AMD Ryzen 7, 64 GB RAM |
| FFT throughput | 960 million FFT points/s |
| I/Q streaming | Unlimited continuous true I/Q streaming via USB 3.0 |
